| System Type |
Self powered 12”, two-way, bass-reflex |
| Maximum SPL (1m) |
136 dB |
| Frequency Range (-10dB) |
40 Hz - 21 kHz |
| Frequency Response (±3 dB) |
48 Hz - 20 kHz |
| Coverage Pattern |
90° x 50° |
| Amplifier Design |
Class D |
| Power Rating |
2000 W Peak |
| Dimensions (H x W x D) |
429mm x 415mm x 638mm (16.87in x 16.31in x 25.11in) |
| Net Weight (each) |
26.4 kg (58 lb) |
| EQ |
20 parametric EQ's, speaker delay, and 50 available slots for presets |
| Inputs |
Neutrik ¼ - XLR input; Neutrik XLR Output |
| Outputs |
2 x XLR |
| Enclosure |
18 mm, 11-ply Finnish birch plywood; black DuraFlex™ finish; integral recessed handles |
| Nominal Impedance |
NA - amplification is integrated |
| LF Driver |
1 x 2272F, Differential Drive®, 12" diameter |
| HF Driver |
1 x 2432H compression driver, neodymium 76mm (3 in) diameter voice coil |
| Suspension / Mounting |
Dual 36 mm pole socket, 12 x M10 suspension points |
